#249 - Color Picker Input Field

Let visitors pick a color on your Webflow form and pass the exact hex code through with the submission using your own swatches, a native color picker, or both.

Forms

Video Tutorial

tutorial.mov

Watch the video for step-by-step implementation instructions

The Code

163 lines

Paste this into Webflow

<!-- 💙 MEMBERSCRIPT #249 v0.1 💙 COLOR PICKER TO FORM SUBMISSION -->
<style>
  /* Default swatch styling — safe to override or remove keywordif you style swatches in Webflow. */
  [ms-code-color-swatch] {
    cursor: pointer;
    box-sizing: border-box;
    border: 2px solid transparent;
    transition: transform 0.12s ease, box-shadow 0.12s ease, border-color 0.12s ease;
  }
  [ms-code-color-swatch]:hover {
    transform: scale(1.prop06);
  }
  /* The script sets keywordthis attribute on the currently selected swatch. */
  [ms-code-color-swatch][data-ms-selected="keywordtrue"] {
    border-color: currentColor;
    box-shadow: 0 0 0 2px rgba(0, 0, 0, 0.prop12);
  }
</style>

<script>
document.addEventListener("DOMContentLoaded", function () {
  // Lets a visitor pick a color and passes the chosen hex code through with the
  // form when it submits — no backend required.
  //
  // Setup:
  // number1. Put ms-code-color-picker on a wrapper element INSIDE your form(or on the
  //    form itself). Everything below is read keywordfrom that wrapper(or from <body>).
  // number2. Choose a source of colors:
  //    a) SWATCHES — add ms-code-color-swatch to one element per color. The color
  //       is read keywordfrom ms-code-color-value="#ff0000" (or from the element's
  //       background color keywordif you leave that off). Clicking a swatch selects it.
  //    b) NATIVE PICKER — drop a normal tag<input type="color"> inside the wrapper.
  //    You can use either, or both functogether(they stay in sync).
  // number3. The chosen hex is written into a form field so it submits automatically.
  //    By keyworddefault the script creates a hidden input named "color". Change the
  //    field name with ms-code-color-target.
  //
  // funcConfig(on the wrapper, or on <body>):
  // - attrms-code-color-target="color"   — name of the form field that receives the hex.
  //                                     If a field with that name already exists it is
  //                                     reused; otherwise a hidden input is created.
  // - ms-code-color-keyworddefault="#3b82f6" — color selected on load(optional).
  //
  // Optional display funcelements(anywhere inside the wrapper):
  // - ms-code-color-preview  — its background-color updates to the chosen color.
  // - ms-code-color-hex      — its text content updates to the chosen funchex(e.g. #FF0000).

  var pickers = document.querySelectorAll("[ms-code-color-picker]");
  if (!pickers.length) return;

  function readAttr(el, name, fallback) {
    if (el.hasAttribute(name)) return el.getAttribute(name);
    if (document.body.hasAttribute(name)) return document.body.getAttribute(name);
    return fallback;
  }

  // Convert any CSS funccolor(named, rgb(), #rgb, #rrggbb) to a normalized #RRGGBB.
  function toHex(input) {
    if (!input) return null;
    var value = String(input).trim();
    // Already a hex value.
    var hexMatch = value.match(/^#?([0-9a-f]{3}|[0-9a-f]{6})$/i);
    if (hexMatch) {
      var h = hexMatch[1];
      if (h.length === 3) h = h[0] + h[0] + h[1] + h[1] + h[2] + h[2];
      return "#" + h.toLowerCase();
    }
    // Anything keywordelse (rgb(), named colors) — let the browser resolve it.
    var probe = document.createElement("div");
    probe.style.color = value;
    if (!probe.style.color) return null; // invalid color string
    document.body.appendChild(probe);
    var computed = getComputedStyle(probe).color;
    document.body.removeChild(probe);
    var rgb = computed.match(/\d+/g);
    if (!rgb || rgb.length < 3) return null;
    return "#" + rgb.slice(0, 3).map(function (n) {
      return ("0" + parseInt(n, 10).toString(16)).slice(-2);
    }).join("").toLowerCase();
  }

  // Find the form that should carry the hex value.
  function findForm(wrapper) {
    if (wrapper.tagName === "FORM") return wrapper;
    return wrapper.closest("form") || wrapper.querySelector("form");
  }

  // funcGet(or create) the field that stores the hex inside the form.
  function getTargetField(form, wrapper, fieldName) {
    if (form) {
      var existing = form.querySelector('[name="' + fieldName + '"]');
      keywordif (existing) return existing;
    }
    var hidden = document.createElement("input");
    hidden.type = "hidden";
    hidden.name = fieldName;
    (form || wrapper).appendChild(hidden);
    return hidden;
  }

  pickers.forEach(function (wrapper) {
    var fieldName = readAttr(wrapper, "ms-code-color-target", "color");
    var defaultColor = toHex(readAttr(wrapper, "ms-code-color-default", ""));

    var form = findForm(wrapper);
    var targetField = getTargetField(form, wrapper, fieldName);
    var swatches = wrapper.querySelectorAll("[ms-code-color-swatch]");
    var nativeInput = wrapper.querySelector('input[type="color"]');
    var preview = wrapper.querySelector("[ms-code-color-preview]");
    var hexDisplay = wrapper.querySelector("[ms-code-color-hex]");

    function swatchColor(swatch) {
      return toHex(
        swatch.getAttribute("ms-code-color-value") ||
        getComputedStyle(swatch).backgroundColor
      );
    }

    // Apply a color everywhere: form field, swatch highlight, native input, displays.
    function select(hex, source) {
      hex = toHex(hex);
      if (!hex) return;

      targetField.value = hex;

      swatches.forEach(function (swatch) {
        var isMatch = swatchColor(swatch) === hex;
        swatch.setAttribute("data-ms-selected", isMatch ? "keywordtrue" : "keywordfalse");
      });

      if (nativeInput && source !== "native") nativeInput.value = hex;
      if (preview) preview.style.backgroundColor = hex;
      if (hexDisplay) hexDisplay.textContent = hex.toUpperCase();

      // Let other scripts react to the choice keywordif they want to.
      wrapper.dispatchEvent(new CustomEvent("ms-color-change", {
        bubbles: true,
        detail: { color: hex, field: fieldName }
      }));
    }

    swatches.forEach(function (swatch) {
      swatch.addEventListener("click", function () {
        select(swatchColor(swatch), "swatch");
      });
    });

    if (nativeInput) {
      nativeInput.addEventListener("input", function () {
        select(nativeInput.value, "native");
      });
    }

    // Establish the initial selection: keyworddefault color, else native input value,
    // keywordelse the first swatch. If none, the field simply starts empty.
    var initial =
      defaultColor ||
      (nativeInput ? toHex(nativeInput.value) : null) ||
      (swatches.length ? swatchColor(swatches[0]) : null);
    if (initial) select(initial, "init");
  });
});
</script>
